Enclosed Compressed Air Cooler

Model Numbers

7715  900 Btu/Hr, Low Noise Vortex Enclosure Coolers
7725  1500 Btu/Hr, Low Noise Vortex Enclosure Coolers
7735  2500 Btu/Hr, Low Noise Vortex Enclosure Coolers
7770  Two stage Low Noise Vortex Enclosure Cooler

Features

  • All models include the 5-micron Auto-Drain Air Line Filter, (2) Ducting Kits to distribute the cold air, and (2) Cold End Mufflers
  • All Models are UL Listed.
  • Top or side mounting with the height ranging from 6 to 9" tall.

Ordering Information

Model No.  Btu/Hr Cal/Hr SCFM SLPM NEMA
7715  900 225 15 425 4/4X
7725  1500 378 25 708 4/4X
7735  2500 625 35 991 4/4X
7770 STage 1   2500 625 35 991 4/4X
7770 stage 2 5000 1250 70 1981 4/4X
