200 - 400W 60mm DIN Rail Enclosure Fan Heater

Model Numbers

FGC3000 230VAC/50Hz DIN Rail Mountable Fan Heater
FGC3001  115VAC/60Hz DIN Rail Mountable Fan Heater


  • DIN Rail Mount
  • PTC Tech. with self regulating characteristics
  • Operating Temperature: 14 to 158°F (-10 to 70°C)
  • Rugged Plastic Housing, IP20
  • 240mm cable for termination
  • Three independent heater circuits fro 200, 300, or 400 watts
  • Independent fan circuit to aid in cooling
  • Approvals UL, CSA, CE, VDE, RoHS

Ordering Information

Part Number Watts at 50°F Fan & Heater Voltage *Delay Fuse Airflow (m3/h)
FGC3000 200/300/400 230VAC/50Hz 6.3A 5.8 (10)
FGC3001 200/300/400 115VAC/60Hz 6.3A 5.8 (10)
* Rec. Time Delay Fuse
 ** Maintain 50mm safe mounting distance between heater and other objects. Maintain 100mm distance at the hot air outlet. It is recommended to use a thermostat to control the heater.
