4" Enclosure Filter Fans GSV

Model Types

GSV1000220  4" Filter Fan, 230 VAC, 35 cfm
GSV1000203  4" Filter Fan, 115 VAC, 35 cfm
GSV1000211 4" Filter Fan, 24DC, 50 cfm
GSF10 4" Exhaust Filter

Features

  • 4" Enclosure Filter Fans
  • Single Hole Cutout, Snap-In Installation
  • Air Flow 35-50cfm
  • Reversible air flow by reversing fan
  • Easy maintenance and filter replacement
  • Protection Class: IP54 NEMA-12
  • Noise Level: 33-53 dB(A)
  • Electrical connections with spring terminals
  • MBTF: 40,000 hours
  • Operating Temperature: 14/158°F (-10/70°C)
  • Approval: CE, cURus, CSA, EAC

Accessories & Options

Exploded Kryos² Filter Fan

Electrical Specifications

Part No. Voltage W/A Fuse Fan Flow Flow Direction
GSV1000220  230VAC 4.6/0.21 0.5A 35 cfm Reversible
GSV1000203  115VAC 3.6/0.22 0.5A 35 cfm Reversible
GSV1000211 24VDC 6.3/0.265 1A 50 cfm Reversible
GSF10         Exhaust only
